Top Concealed Mounting Electric Swing Door Opener
Top Concealed Mounting Electric Swing Door Opener
DSW 4 type top concealed mounting electric door opener, concealed installation, can achieve the automatic opening and closing of all kinds of casement doors, can be applied to various public places such as spring doors, revolving doors, etc.
Features For Top Concealed Mounting Electric Swing Door Opener
- Multi-stage gear transmission, high torque output.
- Low-noise design to ensure the quiet effect of indoor operation.
- Hidden installation, the overall effect is good.
- Intelligent chip and core power to ensure smarter and safer product operation.
- Good reversibility, the door can be moved at will during operation, and it is not easy to damage.
- Can be linked with two machines to make single-door single-open,double-door single-open, double-door double-open.
- Can be set to two-door synchronous, two-door asynchronous mode.
- Can be connected with magnetic lock and electric lock.
- Suitable for all kinds of doors, frameless glass doors / framed glass doors / metal doors / wooden doors, etc.
Top Concealed Mounting Electric Swing Door Opener Technical Specifications
| Material of product: | 304 stainless steel, zinc alloy | Temperature: | -20°C~+50°C |
| Suitable door weight: | <=70kg | Voltage: | 220V-240V 50Hz |
| Opening time: | 3-7s | Maximum opening angle: | 105 degree |
|
Door opening holding time: |
1-30s | IP: | IP12D |
| Width of door leaf: | <=900mm |
We Also Recommend
QUESTIONS & ANSWERS
Ask a Question-
Good morning Can i force open and close the door without damaging the mechnism? This will enable me to open and close the door without waiting for the electronic mechanism
Hi, this model does not allow manual opening and closing the door, it can only be opened with switch or sensor. If you want to open the door manually, you can consider the model Olide-120B, it with Push&Go feature, manual push the door, it will open automatically, the motor is still engaged.
